Description
Features:
- 3/8″ Male Compression Connection
- 3/8″ Female Compression Connection
- 3/8″ OD JG Connection
- Polypropylene Body
- Polysulfone Shaft
- EPDM O-Rings
- Stainless Steel Gripper
- 145 Max. Working Pressure @ 68° F
- 58 Max. Working Pressure @ 140° F
- Made with same quality materials required by NSF-61
Fittings Comparison: Polypropylene White
|
Size |
NEO: Working PSI @ Temp |
JG: Working PSI @ Temp |
DM Fit: Working PSI@ Temp | Mur-Lok: Working PSI@ Temp |
|---|---|---|---|---|
|
1/4″ |
150psi @ 68F/ 60psi @ 150F | 150psi @ 70F/ 60psi at 140F | 150psi @ 70F/ 60psi @ 150F | 150psi @ 70F/ 60psi @ 140F |
|
3/8″ |
150psi @ 68F/ 60psi @ 150F |
150psi @ 70F/ 60psi at 140F |
150psi @ 70F/ 60psi @ 150F | 150psi @ 70F/ 60psi @ 140F |
|
1/2″ |
150psi @ 68F/ 60psi @ 150F |
150psi @ 70F/ 60psi at 140F |
150psi @ 70F/ 60psi @ 150F | 150psi @ 70F/ 60psi @ 140F |
|
Certifications |
NEO: NSF 51 & 61 Certified |
JG: NSF 51 & 61 Certified |
DM Fit: NSF 51 & 61 Certified | Mur-Lok: NSF 58 & 372 Certified |
|
Size |
NEO: Max Torque |
JG: Max Torque |
DM Fit: Max Torque |
Mur-Lok: Max Torque |
|---|---|---|---|---|
|
1/4″ |
1ft/lb (1.5nm) |
1ft/lb (1.5nm) |
1ft/lb (1.5nm) |
1ft/lb (1.5nm) |
|
3/8″ |
2ft/lb (3 nm) |
2ft/lb (3 nm) |
2ft/lb (3 nm) |
2ft/lb (3 nm) |
|
1/2″ |
2ft/lb (3 nm) |
2ft/lb (3 nm) |
2ft/lb (3 nm) |
2ft/lb (3 nm) |
