Description
High-Performance Turbo for 2.0L – 3.5L Engines | 350-725 HP | Standard Rotation
Product Overview
The Garrett G-Series II G30-725 Turbocharger is designed to deliver maximum performance, faster spool, and superior efficiency for 2.0L – 3.5L engines. This turbo supports 350-725 horsepower, making it an ideal choice for high-performance street builds, track cars, and race applications.
With next-generation compressor aerodynamics, the G-Series II increases flow by up to 10% more than the previous generation. It also retains compatibility with G-Series Gen I housings, ensuring an easy upgrade path for existing users.
Turbine Housing Options (Select from Dropdown)
The G30-725 is available in two turbine A/R options, allowing you to fine-tune performance based on your engine setup:
- 0.83 A/R (PN: 934118-5001S) – Faster spool, great for street-driven performance builds.
- 1.01 A/R (PN: 934118-5002S) – Higher flow, optimized for top-end power in race applications.
👉 Use the dropdown menu to select the right turbine housing for your performance goals!
Key Features & Benefits
✔ Advanced Compressor Technology – Increased efficiency, faster spool, and higher power potential.
✔ Up to 10% More Flow – Compared to Gen I, providing better boost response and top-end performance.
✔ Direct Gen I Upgrade – Retains Gen I compressor and turbine housings, simplifying installation.
✔ Pre-Assembled & Calibrated – Includes a 0.5 bar actuator for precise boost control.
✔ Internal Wastegate – Simplifies integration for OEM and custom applications.
Technical Specifications
General Specs
- Horsepower Range: 350-725 HP
- Engine Displacement: 2.0L – 3.5L
- Rotation: Standard
- Actuator: Pre-installed and calibrated at 0.5 bar
Compressor Specs
- Inducer: 54mm
- Exducer: 67mm
- Trim: 65
- A/R: 0.70
Turbine Specs (Varies by Selection)
- Inducer: 60mm
- Exducer: 55mm
- Trim: 84
- A/R Options: 0.83 / 1.01 (select from dropdown)
Fitment & Installation
The Garrett G30-725 Turbocharger is built for performance-driven applications, offering multiple A/R options to fine-tune your setup:
- 0.83 A/R: Best for quick spool and street-driven performance builds.
- 1.01 A/R: Optimized for top-end power and high-boost race applications.
Why Choose the Garrett G-Series II G30-725?
For drivers looking to push their engine’s power output while maintaining faster spool and efficiency, the Garrett G30-725 is the perfect upgrade. Whether you’re building a high-performance street car or a full race machine, this turbocharger delivers cutting-edge power and response.
🔧 Select your preferred A/R from the dropdown to match your build!
📄 Garrett G-Series II Product Flyer »
