CAT C15 S410SX Turbocharger 14969880001 – 80mm, 1.58 A/R Optimized Flow

Description

14969880001 CAT C-15 S410SX TURBO 80MM 1.58 A/R

600-900 (HP Turbo-15L Diesel)

• Compressor Wheel Outside Diameter (in): 4.32
• Compressor Wheel Outside Diameter (mm): 109.73
• Compressor Wheel Inducer Diameter (in): 3.16
• Compressor Wheel Inducer Diameter (mm): 80.30
• Turbine Wheel Outside Diameter (in): 3.77
• Turbine Wheel Outside Diameter (mm): 95.70
• Turbine Wheel Exducer (in): 3.47
• Turbine Wheel Exducer (mm): 88.05
• Turbine Housing A/R: 1.58
