Description

BorgWarner S500SX Cartridge

BorgWarner S500SX Key Cartridge Features

• Twin hydrodynamic journal bearings
• Extended Tip Technology Compressor Wheel
• Available twin scroll and open flow turbine volute options
• Available Adjustable compressor and turbine housing orientation
• Available Standard turbine inlet and outlet allows for drop-in to existing turbocharded applications
• Available Compressor cover recirculation grooves
• Available Optimized compressor inlet geometry
• Available Dual machined compressor cover discharge connection (v-band or hose bead)
• Available Premachined speed sensor mounting boss

BorgWarner S500SX Cartridge 179187

Features:

• Comp Wheel OD (in): 4.73
• Comp Wheel Inducer (in): 120.20
• Comp Wheel Inducer (mm): 88.19
• Turbine Wheel OD (mm): 109.73
• Turbine Wheel Exducer (in): 3.90
• Turbine Wheel Exducer (mm): 99.08

THIS IS JUST A CARTRIDGE. NO COMPRESSOR COVER OR TURBINE HOUSING.
